1. Grant Proposal Summary Title: Multi-Modal Diamond Detection Horn Using Sonic, Electromagnetic, and Thermal Sensor Fusion Project Summary: This project introduces a novel, handheld detection instrument capable of identifying diamonds with unparalleled precision and non-invasive accuracy. The device integrates a sonic pulse oscillator, electrostatic emitter, Hall effect sensors, air coil solenoid, and thermal microwave vector tracking—fused into a singular detection architecture. It eliminates false positives through real-time data correlation across thermal, acoustic, electromagnetic, and proximity sensory inputs. Scientific Merit: This technology addresses critical needs in geological exploration, border security, and materials verification by reducing reliance on invasive, costly, or inconclusive traditional detection methods. The project is rooted in applied physics, electromagnetism, and signal processing. Funding Use: Requested grant support will fund: (1) functional prototype development, (2) sensor calibration trials on natural and synthetic diamonds, (3) software algorithm training using a mineral signature database, and (4) manufacturing optimization for field deployment. 2. Pitch Deck Summary Slide Title: Introducing the Next-Gen Diamond Detection Horn Problem: Current gem identification tools are bulky, invasive, and often inaccurate, especially when it comes to detecting diamonds in situ or through concealment. Solution: Our compact, horn-shaped device combines sonic, magnetic, thermal, and proximity sensors to uniquely identify real diamonds—fast, non-invasively, and with AI-powered accuracy. Technology Highlights: Sonic Pulse Mapping – interprets crystal density echoes Hall Effect & Magnetic Push-Pull Solenoid – rules out false metal readings Thermal Microwave Signature Analysis – pinpoints authentic diamonds Proximity Vector Sensing – locates diamonds through barriers Market Opportunity: Jewelers & gemologists Mining and resource exploration Law enforcement & customs High-security asset scanning Traction & Ask: Seeking partners and $500k in seed funding to finalize hardware and software for pilot distribution. 3. Patent Summary Title: Sonic-Electromagnetic Diamond Detection Horn Abstract: The invention relates to a handheld detection apparatus designed to identify diamonds using a horn-type array of integrated sensors. It combines acoustic, electrostatic, electromagnetic, thermal, and spatial sensing into a portable unit. Key components include a sonic pulse oscillator, electrostatic emitter coil, Hall effect sensor array, air coil-type solenoid, thermal microwave emitter, temperature vector sensors, and proximity sensory grid. The system uses multi-signal data fusion to accurately discriminate diamonds from other crystalline or mineral-based materials. Inventor: Jermaine Morton Application Use: Geological exploration, gem verification, customs inspection, high-value security scanning. 1. Patent Title Sonic-Electromagnetic Diamond Detection Horn Utilizing Multi-Modal Sensory Systems 2. Abstract The invention is a portable, horn-type diamond detector that integrates sonic pulse oscillation, electrostatic emission, Hall effect sensing, air coil-type solenoids, microwave thermal analysis, temperature vector sensory, and proximity-based detection. It is designed to non-invasively detect and distinguish diamonds from other substances using a dynamic multi-sensory array. 3. Utility Patent Claims (Draft) Independent Claims Claim 1: A diamond detection apparatus comprising: a horn-shaped housing; a sonic pulse oscillator positioned within said housing, configured to emit directional ultrasonic pulses; an electrostatic emitter adjacent to the oscillator, configured to apply a charge field to target materials; a Hall effect sensor configured to detect electromagnetic field variations caused by non-diamond materials; an air coil-type solenoid configured to produce a push-pull magnetic field for material interaction analysis; a thermal microwave emitter and receiver configured to analyze dielectric and heat signature properties of a substance; a temperature vector sensor configured to detect micro-temperature shifts and thermal gradients of nearby materials; and a proximity sensory array configured to generate spatial maps and locate diamonds based on density and reflectivity. Claim 2: The apparatus of claim 1, wherein the sonic oscillator generates frequency pulses between 20 kHz to 80 kHz for optimal diamond surface resonance. Claim 3: The apparatus of claim 1, wherein the electrostatic emitter uses a high-voltage low-current discharge system to measure dielectric constant variation in insulating materials. Dependent Claims Claim 4: The apparatus of claim 1, further comprising a processor configured to compare sensory input with a database of known diamond signatures for material confirmation. Claim 5: The apparatus of claim 1, wherein the proximity sensor integrates LiDAR, IR reflectivity, and thermal imaging for composite spatial analysis. Claim 6: The apparatus of claim 1, wherein the air coil solenoid is dynamically tuned to alternate between magnetic push and pull cycles at variable frequency rates. Claim 7: The apparatus of claim 1, wherein the temperature vector sensor maps thermal conductivity patterns over time to distinguish synthetic diamond simulants. 4. Figure Diagrams (Descriptions) Figure 1: Device Perspective View Horn-shaped outer housing Handheld grip Control interface panel Figure 2: Internal Cross-Section (A) Sonic Pulse Oscillator (B) Electrostatic Emitter Coil (C) Hall Effect Sensor Array (D) Air Coil Solenoid (E) Thermal Microwave Emitter (F) Microwave Receiver (G) Temperature Vector Sensor (H) Proximity Sensory Grid (I) Processing Unit (J) Power Supply Figure 3: Signal Pathway Block Diagram Sonic pulse → material echo → data capture Electrostatic charge → discharge response → dielectric reading Magnetic field interaction → Hall sensor → voltage curve analysis Microwave pulse → absorption/reflection curve All data routed to processor → diamond determination logic 5. Prototype Design Plan Hardware Components Housing: ABS polymer shell with aluminum horn throat for resonance Oscillator: Piezoelectric transducer (ultrasonic, tunable) Emitter: Corona discharge tip with Faraday cage insulation Magnetic System: Dual winding copper air coil with permanent magnet core Sensors: Hall effect chip (e.g., Allegro A1324) Microwave antenna with thermal tracking IR and thermal imaging for proximity mapping Processor: Microcontroller with DSP capability (STM32 or Arduino Mega w/ sensor integration) Software System Signal Processing: FFT-based echo analysis Data Fusion: Neural network trained on gem signatures GUI: Real-time sensory display with alert system Modes: "Scan", "Compare", "Map", and "Calibrate"
